HRN-200 Adjustable Nozzle

Introducing the Husqvarna HRN 200 Adjustable Spray Nozzle – the ultimate solution for precision irrigation! Designed and engineered by our seasoned experts in landscape irrigation, this nozzle is the epitome of performance and versatility. With its exceptional features and unmatched quality, it’s sure to exceed your expectations. Let’s dive into some of the benefits that make the HRN 200 a game-changer:

1. Customizable Coverage: Say goodbye to one-size-fits-all irrigation! The HRN 200 allows you to adjust the spray arc, giving you full control over the coverage area. Whether you need wide-reaching sprays or targeted watering, this nozzle has got you covered. Simply set the desired arc and let the HRN 200 deliver water precisely where you need it.
2. Stop Feature for Precision: We understand the importance of precise positioning. That’s why our engineers incorporated a unique stop feature into the HRN 200. This ingenious design prevents over-rotation during adjustment, ensuring that your spray pattern stays perfectly aligned. No more accidental movement or misalignment – just precise and efficient irrigation every time.
3. Easy Identification: We know how valuable your time is, which is why we’ve made it incredibly easy to identify the HRN 200 nozzle you need. The top of the nozzle is color-coded according to the spray radius, allowing you to quickly and accurately select the correct nozzle for your specific irrigation zone. It’s hassle-free and saves you from any guesswork.
4. Optimal Performance: The HRN 200 is engineered to deliver outstanding performance within a pressure range of 15-30 PSI. Our commitment to superior quality ensures that you can rely on this nozzle for consistent and efficient watering. Plus, its filtration system safeguards against clogging, providing a hassle-free irrigation experience.
5. Water Conservation: Husqvarna prides itself on supporting sustainable irrigation practices. With the HRN 200’s lower precipitation rate, you can be confident that you’re minimizing water waste. This not only helps the environment but also saves you money by reducing water consumption without compromising the health of your landscape.

When you choose the HRN 200 Adjustable Spray Nozzle, you’re investing in a product born from Husqvarna’s expertise and relentless dedication to customer satisfaction. Experience the difference of a high-quality, dependable irrigation solution that puts you in control. Join the countless professionals who trust Husqvarna.

Built for Speed Advantages

• Fastest to Find—Color-coded according to spray radius, making identification a snap. And the color isn’t just painted on like other nozzles. The color is added to plastic top so each nozzle can withstand years of abuse. Nozzles and filters come in separate, re-sealable bags for complete organization.
• Fastest to Install—Coin-edging around top of nozzle gives excellent grip-ability no matter the conditions and the exclusive color-coded arc edge indicator lets you set a precise pattern fast.
• Fastest to Fine Tune—Exclusive adjustment slot allows use of a screwdriver to give fine arc adjustment during operation, without intruding into the spray pattern.

Built for Green Advantages

• Lower Precipitation Rate—Matched precipitation, combined with outstanding distribution uniformity and lower precipitation rate than competition, generates improved efficiency.
• Arc Edge Technology—Three-piece design provides best-in-class right and left arc edges, optimizing distribution uniformity.
• Oversized Filter—Large .02 x .02 blue mesh filter reduces maintenance and ensures precipitation rate remains at optimal levels longer.

Features and Benefits

• Full Arc Adjustment—0°~360° matched precipitation.
• Color-coded Arc Edge Indicator—Eliminates all guesswork by indicating left and right arc edges with water on or off.
• Three-piece Design—Nozzle stop stays flush to wiper seal across full range of arc adjustment, minimizing susceptibility to damage from lawn equipment and traffic.
• Stainless Steel Adjustment—Slotted screw provides precise radius adjustment.
• Compatibility—Fits Husqvarna^®, Rain Bird^®, Hunter^®, and other male threaded spray body sprinklers.

Weight	N/A
Dimensions	N/A
Radius	10 Feet, 12 Feet, 15 Feet, 18 Feet, 4 Feet, 8 Feet
Operating pressure	30 PSI
Flow Rate	0.39 – 8.97 GPM

Documentation

[fliph5 id=”aerit-nfud” width=”900px” height=”500px”] [fliph5 id=”aerit-pjli” width=”900px” height=”500px”]

Performance Chart - Imperial

Nozzle	Pattern	Arc	pressure (psi)	Radius (ft)	FLOW (GPM)	Precip rate SQ (in/hr)	Precip rate Tri (in/hr)
4A	Quarter	90	20	4	0.61	14.75	17.03
4A	Quarter	90	25	5	0.67	12.65	14.61
4A	Quarter	90	30	5	0.73	11.22	12.95
4A	Quarter	90	35	6	0.79	10.07	11.63
4A	Quarter	90	40	6	0.84	8.97	10.36
4A	Half	180	20	4	1.23	14.75	17.03
4A	Half	180	25	5	1.33	12.65	14.61
4A	Half	180	30	5	1.46	11.22	12.95
4A	Half	180	35	6	1.58	10.07	11.63
4A	Half	180	40	6	1.68	8.97	10.36
4A	Three-Quarter	270	20	4	1.84	14.75	17.03
4A	Three-Quarter	270	25	5	2.00	12.65	14.61
4A	Three-Quarter	270	30	5	2.18	11.22	12.95
4A	Three-Quarter	270	35	6	2.37	10.07	11.63
4A	Three-Quarter	270	40	6	2.52	8.97	10.36
4A	Full	360	20	4	2.45	14.75	17.03
4A	Full	360	25	5	2.66	12.65	14.61
4A	Full	360	30	5	2.91	11.22	12.95
4A	Full	360	35	6	3.16	10.07	11.63
4A	Full	360	40	6	3.36	8.97	10.36
8A	Quarter	90	20	7	0.39	3.03	3.49
8A	Quarter	90	25	8	0.42	2.77	3.20
8A	Quarter	90	30	8	0.46	2.55	2.95
8A	Quarter	90	35	9	0.50	2.37	2.73
8A	Quarter	90	40	9	0.53	2.33	2.70
8A	Half	180	20	7	0.77	3.03	3.49
8A	Half	180	25	8	0.85	2.77	3.20
8A	Half	180	30	8	0.92	2.55	2.95
8A	Half	180	35	9	1.00	2.37	2.73
8A	Half	180	40	9	1.06	2.33	2.70
8A	Three-Quarter	270	20	7	1.16	3.03	3.49
8A	Three-Quarter	270	25	8	1.27	2.77	3.20
8A	Three-Quarter	270	30	8	1.38	2.55	2.95
8A	Three-Quarter	270	35	9	1.49	2.37	2.73
8A	Three-Quarter	270	40	9	1.58	2.33	2.70
8A	Full	360	20	7	1.54	3.03	3.49
8A	Full	360	25	8	1.69	2.77	3.20
8A	Full	360	30	8	1.84	2.55	2.95
8A	Full	360	35	9	1.99	2.37	2.73
8A	Full	360	40	9	2.11	2.33	2.70
10A	Quarter	90	20	9	0.39	1.83	2.11
10A	Quarter	90	25	10	0.42	1.80	2.08
10A	Quarter	90	30	10	0.46	1.77	2.05
10A	Quarter	90	35	11	0.50	1.74	2.01
10A	Quarter	90	40	11	0.53	1.68	1.94
10A	Half	180	20	9	0.77	1.83	2.11
10A	Half	180	25	10	0.85	1.80	2.08
10A	Half	180	30	10	0.92	1.77	2.05
10A	Half	180	35	11	1.00	1.74	2.01
10A	Half	180	40	11	1.06	1.68	1.94
10A	Three-Quarter	270	20	9	1.16	1.83	2.11
10A	Three-Quarter	270	25	10	1.27	1.80	2.08
10A	Three-Quarter	270	30	10	1.38	1.77	2.05
10A	Three-Quarter	270	35	11	1.49	1.74	2.01
10A	Three-Quarter	270	40	11	1.58	1.68	1.94
10A	Full	360	20	9	1.54	1.83	2.11
10A	Full	360	25	10	1.69	1.80	2.08
10A	Full	360	30	10	1.84	1.77	2.05
10A	Full	360	35	11	1.99	1.74	2.01
10A	Full	360	40	11	2.11	1.68	1.94
12A	Quarter	90	20	12	0.51	1.48	1.71
12A	Quarter	90	25	12	0.55	1.46	1.68
12A	Quarter	90	30	13	0.58	1.43	1.65
12A	Quarter	90	35	13	0.62	1.41	1.63
12A	Quarter	90	40	14	0.65	1.37	1.58
12A	Half	180	20	12	1.02	1.48	1.71
12A	Half	180	25	12	1.09	1.46	1.68
12A	Half	180	30	13	1.16	1.43	1.65
12A	Half	180	35	13	1.24	1.41	1.63
12A	Half	180	40	14	1.30	1.37	1.58
12A	Three-Quarter	270	20	12	1.52	1.48	1.71
12A	Three-Quarter	270	25	12	1.64	1.46	1.68
12A	Three-Quarter	270	30	13	1.74	1.43	1.65
12A	Three-Quarter	270	35	13	1.86	1.41	1.63
12A	Three-Quarter	270	40	14	1.95	1.37	1.58
12A	Full	360	20	12	2.03	1.48	1.71
12A	Full	360	25	12	2.18	1.46	1.68
12A	Full	360	30	13	2.33	1.43	1.65
12A	Full	360	35	13	2.48	1.41	1.63
12A	Full	360	40	14	2.60	1.37	1.58
15A	Quarter	90	20	13	0.59	1.34	1.54
15A	Quarter	90	25	14	0.65	1.27	1.46
15A	Quarter	90	30	15	0.69	1.27	1.47
15A	Quarter	90	35	15	0.74	1.27	1.47
15A	Quarter	90	40	16	0.79	1.19	1.38
15A	Half	180	20	13	1.17	1.34	1.54
15A	Half	180	25	14	1.29	1.27	1.46
15A	Half	180	30	15	1.39	1.27	1.47
15A	Half	180	35	15	1.49	1.27	1.47
15A	Half	180	40	16	1.59	1.19	1.38
15A	Three-Quarter	270	20	13	1.76	1.34	1.54
15A	Three-Quarter	270	25	14	1.94	1.27	1.46
15A	Three-Quarter	270	30	15	2.08	1.27	1.47
15A	Three-Quarter	270	35	15	2.23	1.27	1.47
15A	Three-Quarter	270	40	16	2.38	1.19	1.38
15A	Full	360	20	13	2.35	1.34	1.54
15A	Full	360	25	14	2.58	1.27	1.46
15A	Full	360	30	15	2.77	1.27	1.47
15A	Full	360	35	15	2.98	1.27	1.47
15A	Full	360	40	16	3.17	1.19	1.38
18A	Quarter	90	20	15	0.68	1.16	1.34
18A	Quarter	90	25	16	0.75	1.13	1.31
18A	Quarter	90	30	17	0.83	1.11	1.28
18A	Quarter	90	35	18	0.90	1.07	1.24
18A	Quarter	90	40	19	0.96	1.02	1.18
18A	Half	180	20	15	1.36	1.16	1.34
18A	Half	180	25	16	1.51	1.13	1.31
18A	Half	180	30	17	1.66	1.11	1.28
18A	Half	180	35	18	1.80	1.07	1.24
18A	Half	180	40	19	1.92	1.02	1.18
18A	Three-Quarter	270	20	15	2.03	1.16	1.34
18A	Three-Quarter	270	25	16	2.26	1.13	1.31
18A	Three-Quarter	270	30	17	2.50	1.11	1.28
18A	Three-Quarter	270	35	18	2.70	1.07	1.24
18A	Three-Quarter	270	40	19	2.88	1.02	1.18
18A	Full	360	20	15	2.71	1.16	1.34
18A	Full	360	25	16	3.01	1.13	1.31
18A	Full	360	30	17	3.33	1.11	1.28
18A	Full	360	35	18	3.61	1.07	1.24
18A	Full	360	40	19	3.84	1.02	1.18

HRN 200 Nozzle Performance Published 2020JUN31. Radius is rounded to the nearest foot, 30 PSI (2.1 bar) is the recommended pressure & adjusting the radius reduction screw/diffuser screw may be required to achieve catalog distance and flow.

Performance Chart - Metric

Nozzle	Pattern	Arc	Pressure (BAR)	Radius (m)	Flow (m^3/hr)	Flow (L/s)	Precip SQ (mm/hr)	Precip TRI (mm/hr)
4A	Quarter	90	1.4	1.2	0.14	0.04	374.55	432.5
4A	Quarter	90	1.7	1.4	0.15	0.04	321.30	371
4A	Quarter	90	2.1	1.5	0.17	0.05	284.96	329.1
4A	Quarter	90	2.4	1.7	0.18	0.05	255.72	295.3
4A	Quarter	90	2.8	1.8	0.19	0.05	227.96	263.2
4A	Half	180	1.4	1.2	0.28	0.08	374.55	432.5
4A	Half	180	1.7	1.4	0.30	0.08	321.30	371
4A	Half	180	2.1	1.5	0.33	0.09	284.96	329.1
4A	Half	180	2.4	1.7	0.36	0.10	255.72	295.3
4A	Half	180	2.8	1.8	0.38	0.11	227.96	263.2
4A	Three-Quarter	270	1.4	1.2	0.42	0.12	374.55	432.5
4A	Three-Quarter	270	1.7	1.4	0.45	0.13	321.30	371
4A	Three-Quarter	270	2.1	1.5	0.50	0.14	284.96	329.1
4A	Three-Quarter	270	2.4	1.7	0.54	0.15	255.72	295.3
4A	Three-Quarter	270	2.8	1.8	0.57	0.16	227.96	263.2
4A	Full	360	1.4	1.2	0.56	0.15	374.55	432.5
4A	Full	360	1.7	1.4	0.60	0.17	321.30	371
4A	Full	360	2.1	1.5	0.66	0.18	284.96	329.1
4A	Full	360	2.4	1.7	0.72	0.20	255.72	295.3
4A	Full	360	2.8	1.8	0.76	0.21	227.96	263.2
8A	Quarter	90	1.4	2.1	0.09	0.02	76.87	88.8
8A	Quarter	90	1.7	2.3	0.10	0.03	70.45	81.400000000000006
8A	Quarter	90	2.1	2.5	0.10	0.03	64.86	74.900000000000006
8A	Quarter	90	2.4	2.7	0.11	0.03	60.09	69.400000000000006
8A	Quarter	90	2.8	2.8	0.12	0.03	59.29	68.5
8A	Half	180	1.4	2.1	0.17	0.05	76.87	88.8
8A	Half	180	1.7	2.3	0.19	0.05	70.45	81.400000000000006
8A	Half	180	2.1	2.5	0.21	0.06	64.86	74.900000000000006
8A	Half	180	2.4	2.7	0.23	0.06	60.09	69.400000000000006
8A	Half	180	2.8	2.8	0.24	0.07	59.29	68.5
8A	Three-Quarter	270	1.4	2.1	0.26	0.07	76.87	88.8
8A	Three-Quarter	270	1.7	2.3	0.29	0.08	70.45	81.400000000000006
8A	Three-Quarter	270	2.1	2.5	0.31	0.09	64.86	74.900000000000006
8A	Three-Quarter	270	2.4	2.7	0.34	0.09	60.09	69.400000000000006
8A	Three-Quarter	270	2.8	2.8	0.36	0.10	59.29	68.5
8A	Full	360	1.4	2.1	0.35	0.10	76.87	88.8
8A	Full	360	1.7	2.3	0.38	0.11	70.45	81.400000000000006
8A	Full	360	2.1	2.5	0.42	0.12	64.86	74.900000000000006
8A	Full	360	2.4	2.7	0.45	0.13	60.09	69.400000000000006
8A	Full	360	2.8	2.8	0.48	0.13	59.29	68.5
10A	Quarter	90	1.4	2.7	0.09	0.02	46.50	53.7
10A	Quarter	90	1.7	2.9	0.10	0.03	45.80	52.9
10A	Quarter	90	2.1	3.0	0.10	0.03	45.01	52
10A	Quarter	90	2.4	3.2	0.11	0.03	44.15	51
10A	Quarter	90	2.8	3.4	0.12	0.03	42.65	49.3
10A	Half	180	1.4	2.7	0.17	0.05	46.50	53.7
10A	Half	180	1.7	2.9	0.19	0.05	45.80	52.9
10A	Half	180	2.1	3.0	0.21	0.06	45.01	52
10A	Half	180	2.4	3.2	0.23	0.06	44.15	51
10A	Half	180	2.8	3.4	0.24	0.07	42.65	49.3
10A	Three-Quarter	270	1.4	2.7	0.26	0.07	46.50	53.7
10A	Three-Quarter	270	1.7	2.9	0.29	0.08	45.80	52.9
10A	Three-Quarter	270	2.1	3.0	0.31	0.09	45.01	52
10A	Three-Quarter	270	2.4	3.2	0.34	0.09	44.15	51
10A	Three-Quarter	270	2.8	3.4	0.36	0.10	42.65	49.3
10A	Full	360	1.4	2.7	0.35	0.10	46.50	53.7
10A	Full	360	1.7	2.9	0.38	0.11	45.80	52.9
10A	Full	360	2.1	3.0	0.42	0.12	45.01	52
10A	Full	360	2.4	3.2	0.45	0.13	44.15	51
10A	Full	360	2.8	3.4	0.48	0.13	42.65	49.3
12A	Quarter	90	1.4	3.5	0.12	0.03	37.55	43.4
12A	Quarter	90	1.7	3.7	0.12	0.03	37.03	42.8
12A	Quarter	90	2.1	3.8	0.13	0.04	36.40	42
12A	Quarter	90	2.4	4.0	0.14	0.04	35.82	41.4
12A	Quarter	90	2.8	4.1	0.15	0.04	34.86	40.299999999999997
12A	Half	180	1.4	3.5	0.23	0.06	37.55	43.4
12A	Half	180	1.7	3.7	0.25	0.07	37.03	42.8
12A	Half	180	2.1	3.8	0.26	0.07	36.40	42
12A	Half	180	2.4	4.0	0.28	0.08	35.82	41.4
12A	Half	180	2.8	4.1	0.29	0.08	34.86	40.299999999999997
12A	Three-Quarter	270	1.4	3.5	0.35	0.10	37.55	43.4
12A	Three-Quarter	270	1.7	3.7	0.37	0.10	37.03	42.8
12A	Three-Quarter	270	2.1	3.8	0.40	0.11	36.40	42
12A	Three-Quarter	270	2.4	4.0	0.42	0.12	35.82	41.4
12A	Three-Quarter	270	2.8	4.1	0.44	0.12	34.86	40.299999999999997
12A	Full	360	1.4	3.5	0.46	0.13	37.55	43.4
12A	Full	360	1.7	3.7	0.50	0.14	37.03	42.8
12A	Full	360	2.1	3.8	0.53	0.15	36.40	42
12A	Full	360	2.4	4.0	0.56	0.16	35.82	41.4
12A	Full	360	2.8	4.1	0.59	0.16	34.86	40.299999999999997
15A	Quarter	90	1.4	4.0	0.13	0.04	33.94	39.200000000000003
15A	Quarter	90	1.7	4.3	0.15	0.04	32.20	37.200000000000003
15A	Quarter	90	2.1	4.4	0.16	0.04	32.25	37.200000000000003
15A	Quarter	90	2.4	4.6	0.17	0.05	32.34	37.299999999999997
15A	Quarter	90	2.8	4.9	0.18	0.05	30.29	35
15A	Half	180	1.4	4.0	0.27	0.07	33.94	39.200000000000003
15A	Half	180	1.7	4.3	0.29	0.08	32.20	37.200000000000003
15A	Half	180	2.1	4.4	0.31	0.09	32.25	37.200000000000003
15A	Half	180	2.4	4.6	0.34	0.09	32.34	37.299999999999997
15A	Half	180	2.8	4.9	0.36	0.10	30.29	35
15A	Three-Quarter	270	1.4	4.0	0.40	0.11	33.94	39.200000000000003
15A	Three-Quarter	270	1.7	4.3	0.44	0.12	32.20	37.200000000000003
15A	Three-Quarter	270	2.1	4.4	0.47	0.13	32.25	37.200000000000003
15A	Three-Quarter	270	2.4	4.6	0.51	0.14	32.34	37.299999999999997
15A	Three-Quarter	270	2.8	4.9	0.54	0.15	30.29	35
15A	Full	360	1.4	4.0	0.53	0.15	33.94	39.200000000000003
15A	Full	360	1.7	4.3	0.59	0.16	32.20	37.200000000000003
15A	Full	360	2.1	4.4	0.63	0.17	32.25	37.200000000000003
15A	Full	360	2.4	4.6	0.68	0.19	32.34	37.299999999999997
15A	Full	360	2.8	4.9	0.72	0.20	30.29	35
18A	Quarter	90	1.4	4.6	0.15	0.04	29.46	34
18A	Quarter	90	1.7	4.9	0.17	0.05	28.78	33.200000000000003
18A	Quarter	90	2.1	5.2	0.19	0.05	28.16	32.5
18A	Quarter	90	2.4	5.5	0.20	0.06	27.22	31.4
18A	Quarter	90	2.8	5.8	0.2	0.1	26	30
18A	Half	180	1.4	4.6	0.3	0.1	29.5	34
18A	Half	180	1.7	4.9	0.3	0.1	28.8	33.200000000000003
18A	Half	180	2.1	5.2	0.4	0.1	28.2	32.5
18A	Half	180	2.4	5.5	0.4	0.1	27.2	31.4
18A	Half	180	2.8	5.8	0.4	0.1	26	30
18A	Three-Quarter	270	1.4	4.6	0.5	0.1	29.5	34
18A	Three-Quarter	270	1.7	4.9	0.5	0.1	28.8	33.200000000000003
18A	Three-Quarter	270	2.1	5.2	0.6	0.2	28.2	32.5
18A	Three-Quarter	270	2.4	5.5	0.6	0.2	27.2	31.4
18A	Three-Quarter	270	2.8	5.8	0.7	0.2	26	30
18A	Full	360	1.4	4.6	0.6	0.2	29.5	34
18A	Full	360	1.7	4.9	0.7	0.2	28.8	33.200000000000003
18A	Full	360	2.1	5.2	0.8	0.2	28.2	32.5
18A	Full	360	2.4	5.5	0.8	0.2	27.2	31.4
18A	Full	360	2.8	5.8	0.9	0.2	26	30

HRN 200 Nozzle Performance Published 2020JUN31. Radius is rounded to the nearest foot, 30 PSI is the recommended pressure, & adjusting the radius reduction screw/diffuser screw may be required to achieve catalog distance and flow.
