AG-PT-15-150-M02

The B-hyve Ag pressure transducer combines performance with value to meet the requirements of original equipment manufacturers. The field-proven polysilicon thin-film pressure sensor provides excellent overpressure capability and outstanding durability despite substantial shock and vibration. A perfect choice for harsh operating environments.

Features

• Pressure Connection 1/2″ Male Pipe Thread
• 1-5 Vdc Output Signal
• 10-foot Shielded Cable pigtail with PVC Jacket and 24 AWG Leads
• Pressure Range 0 – 150 psi
• TEBA +/-1.0% of span from -4 to 185 Degree F
• TEBA +/-1.5% of span from -40 to 40 Degrees F
• IP66 rating
• 304 Stainless Steel

Instruction Manuals

Transmitter Instruction Sheet
